AGKABEL Parallel Twin Flexible Cables (Battery Cables) – 0.6/1kV
AGKABEL GRUPPE LIMITED presents the Parallel Twin Flexible Cables, engineered for reliable power connections in demanding environments. Designed for use by telecom companies for phone equipment, battery cables for indoor and outdoor use, in dry as well as wet locations on motorized vehicles, or battery-powered equipment such as forklifts and field conveyors. These cables are also ideal for high-quality booster cables. The NBR Elastomer insulation and transparent PVC sheath ensure excellent flexibility, durability, and resistance to cold.
Construction & Standards
-
Standard: AS/NZS 5000, AS/NZS 1125, IEC 60332-1, AS/NZS 3808
-
Voltage: 0.6/1kV
-
Conductor: Plain annealed copper stranded to IEC 60228 Class 6 (Flexible)
-
Insulation: NBR Elastomer (Red/Black or Red/Blue)
-
Sheath: Transparent PVC compound resistant to cold
-
Temperature Range:
-
Static: -30°C to +75°C
-
Flexible: -20°C to +75°C
-
-
Sheath Marking: Manufacture name (trademark) and type, Production year/week or batch number, Metre-marked
Application
Designed for use by Telecoms companies for phone equipment, battery cables for use indoors and outdoors, in dry as well as wet locations on motorised vehicles, or battery powered equipment such as fork lifts, field conveyors etc. Also in high quality booster cables.
Technical Specifications Table
| Conductor (mm²) | No. of strands | Strands Dia. (mm) | Insulation Thickness (mm) | Overall Diameter (mm) | Single Phase Voltage Drop (Mv/Am) | Max. DC Resistance at 20°C (Ohm/km) | Approx. Weight (kg/km) |
|---|---|---|---|---|---|---|---|
| 2*1.5 | 48/0.2 | 1.60 | 0.8 | 4.8×7.4 | 33.00 | 13.300 | 84 |
| 2*2.5 | 80/0.2 | 2.05 | 1.0 | 5.5×12 | 19.40 | 7.980 | 95 |
| 2*4.0 | 127/0.2 | 2.60 | 1.0 | 6.0×13 | 12.00 | 4.950 | 120 |
| 2*6.0 | 172/0.2 | 3.05 | 1.0 | 6.5×14 | 8.00 | 3.300 | 160 |
| 2*10 | 304/0.2 | 4.05 | 1.0 | 8.0×17 | 4.80 | 1.910 | 270 |
| 2*16 | 462/0.2 | 5.00 | 1.0 | 9.8×19.6 | 2.90 | 1.210 | 400 |
| 2*25 | 742/0.2 | 6.30 | 1.2 | 11.30×23 | 1.80 | 0.780 | 605 |
| 2*35 | 1050/0.2 | 7.50 | 1.2 | 12.5×26 | 1.30 | 0.554 | 780 |
| 2*50 | 1482/0.2 | 8.90 | 1.4 | 14.5×30 | 0.99 | 0.386 | 1150 |
| 2*70 | 2092/0.2 | 10.60 | 1.4 | 16.0×33 | 0.67 | 0.272 | 1580 |
Factory Overview
Packaging & Shipping
❓ Frequently Asked Questions (FAQ)
1. What are the primary applications for this cable?
It is designed for:
-
Telecom companies for phone equipment
-
Battery cables for indoor and outdoor use, in dry and wet locations on motorized vehicles
-
Battery-powered equipment such as forklifts and field conveyors
-
High-quality booster cables
2. What is the temperature range of this cable?
-
Static: -30°C to +75°C
-
Flexible: -20°C to +75°C
3. What materials are used for the conductor and insulation?
The conductor is Plain Annealed Copper stranded to IEC 60228 Class 6 (Flexible). The insulation is NBR Elastomer (Red/Black or Red/Blue) and the sheath is a Transparent PVC compound resistant to cold.
4. What is the voltage rating of this cable?
The voltage rating is 0.6/1kV.
5. What standards does this cable comply with?
It complies with AS/NZS 5000, AS/NZS 1125, IEC 60332-1, and AS/NZS 3808.
6. What sizes are available?
Available sizes range from 2*1.5mm² to 2*70mm².
7. What is the benefit of the parallel twin construction?
The parallel twin construction allows for easy separation of the two cores for termination and provides a compact, space-saving profile for battery and booster cable applications.
