AGKABEL Flexible Flat Neoprene Cable – 0.6/1kV, 75°C

AGKABEL GRUPPE LIMITED presents the Flexible Flat Neoprene Cable, engineered for reliable power and control in dynamic material handling applications. Designed for use in indoor and outdoor crane and festooning systems, conveyor systems, and energy chains, this cable offers excellent flexibility and durability. The EPR insulation and PCP Rubber sheath provide superior resistance to heat, oil, and mechanical stress, ensuring long service life in demanding environments.

Construction & Standards

Standard: AS/NZS 5000, IEC 60332-1, IEC 60245
Voltage: 0.6/1kV
Conductor: Conductor stranded for IEC228 (Up to 25mm² – Class 6; 35mm² and above – Class 5)
Insulation: EPR Type 3G13 V90 (Brown, Black, Grey, Blue, G/Y or Black Numbered, G/Y)
Sheath: PCP Rubber Type 5GM5 Black
Temperature Range:
- Fixed: -40°C to +75°C
- Flexing: -5°C to +70°C
Sheath Marking: Manufacture name (trademark) and type, Production year/week or batch number, Metre-marked

Application
Materials and Handling Systems. Suitable for use in Indoor and Outdoor Crane and Festooning Systems, conveyor systems and energy chains.

Technical Specifications Table

Conductor (mm²)	No. of strands	Strands Dia. (mm)	Insulation Thickness (mm)	Overall Diameter (mm)	3 Phase Volt Drop (Mv/Am)	Max. DC Resistance at 20°C (Ohm/km)	Approx. Weight (kg/km)
*42.5**	140/0.15	2.10	0.9	7.2*19.6	16.400	8.030	316
*44.0**	224/0.15	2.60	1.0	8.8*24.2	10.200	5.010	506
*410**	320/0.20	4.20	1.2	10.4*30.8	4.050	1.950	1027
*416**	512/0.20	5.30	1.2	11.6*35.6	2.550	1.260	1430
*435**	280/0.40	7.90	1.4	15.8*50.8	1.170	0.581	2460
*470**	356/0.50	11.00	1.6	21.0*68.0	0.609	0.293	4480
*4120**	614/0.50	14.50	1.8	25.5*84.2	0.366	0.166	7240
*52.5**	140/0.15	2.10	0.9	7.2*27.8	16.400	8.030	391
*54.0**	224/0.15	2.60	1.0	8.8*33.4	0.990	5.010	621
*510**	320/0.20	4.20	1.2	10.4*41.6	4.050	1.950	1171
*516**	512/0.20	5.30	1.2	12.2*48.2	2.550	1.260	1590
*72.5**	140/0.15	2.10	0.9	7.2*36.1	16.400	8.030	533
*76.0**	192/0.20	3.30	1.0	9.6*47.2	6.800	3.420	1004
*81.5**	84/0.15	1.60	0.8	5.9*34.0	30.000	13.800	441
*82.5**	140/0.15	2.10	0.9	7.2*40.2	16.400	8.030	602
*241.5**	84/0.15	1.60	0.8	13.0*56.0	30.000	13.800	1290
*242.5**	140/0.15	2.10	0.9	15.5*66.8	16.400	8.030	1480

Factory Overview

Packaging & Shipping

❓ Frequently Asked Questions (FAQ)

1. What are the primary applications for this cable?
It is suitable for indoor and outdoor crane and festooning systems, conveyor systems, and energy chains, as well as other materials and handling systems.

2. What is the temperature range of this cable?

Fixed: -40°C to +75°C
Flexing: -5°C to +70°C

3. What materials are used for the conductor and insulation?
The conductor is stranded copper (Class 6 up to 25mm², Class 5 above 35mm²). The insulation is EPR Type 3G13 V90 and the sheath is PCP Rubber Type 5GM5 Black.

4. What is the voltage rating of this cable?
The voltage rating is 0.6/1kV.

5. What standards does this cable comply with?
It complies with AS/NZS 5000, IEC 60332-1, and IEC 60245.

6. What sizes and core configurations are available?
Available in configurations from 4 to 24 cores, with conductor sizes ranging from 1.5mm² to 120mm².

7. What is the benefit of the flat construction?
The flat construction is ideal for festooning systems and cable chains, as it prevents twisting and allows for neat, space-saving installation in dynamic applications.
