AGKABEL Multicore Silicone Rubber Flexible Cable – 450/750V
High-temperature, flexible multicore cable designed for demanding industrial and commercial applications. Features Tinned Copper Class 5 conductors and Silicone Rubber insulation with a tear-resistant silicone sheath. Compliant with AS/NZS 3808 and IEC 60332-1. Working temperature range: -60°C to +180°C. Available in 2 to 19 cores from 0.75mm² to 6.0mm². RoHS Compliant.
AGKABEL GRUPPE LIMITED presents the Multicore Silicone Rubber Flexible Cable, engineered for superior performance in extreme temperatures and safety-critical environments. The combination of Tinned Copper Class 5 conductors and Silicone Rubber insulation—protected by a tear-resistant silicone sheath—makes this cable highly flexible and durable. It is ideal for a wide range of applications including electric signs, spotlights, public lighting, electric motor applications, power supplies, electrical appliances, heavy industry, medical areas, and railway and shipping construction.
Construction & Standards
-
Standard: AS/NZS 3808, IEC 60332-1
-
Voltage: 450/750 Volt
-
Conductor: Tinned copper conductors stranded to IEC 60228 Class 5 (Flexible)
-
Insulation: Silicone rubber
-
Sheath: Silicone rubber of tear resistant compound
-
Working Temperature: -60°C to +180°C
-
Sheath Marking: Manufacture name (trademark) and type, Production year/week or batch number, Metre-marked
-
Compliance: RoHS Compliant
Application
Electric signs, spotlights, public lighting; Electric motor applications; Power supplies; Electrical appliances; Heavy industry; Medical areas; Railway and shipping construction.
Technical Specifications Table
| No. of Cores/mm² | No. of strands | Wire/Dia. (mm) | Strands Dia. (mm) | Approx. Diameter (mm) | Max. DC Resistance at 20°C (Ohm/km) | Approx. weight (kg/km) |
|---|---|---|---|---|---|---|
| 2*1 | 32 | 0.20 | 1.30 | 6.6 | 20.00 | 76 |
| 3G0.75 | 24 | 0.20 | 1.13 | 6.8 | 26.70 | 76 |
| 3G1.0 | 32 | 0.20 | 1.30 | 7.4 | 20.00 | 93 |
| 3G1.5 | 30 | 0.25 | 1.60 | 8.0 | 13.70 | 117 |
| 3G2.5 | 50 | 0.25 | 2.00 | 9.7 | 8.21 | 179 |
| 4G0.75 | 24 | 0.20 | 1.13 | 7.8 | 26.70 | 101 |
| 4G1.0 | 32 | 0.20 | 1.30 | 8.1 | 20.00 | 113 |
| 4G1.5 | 30 | 0.25 | 1.60 | 8.8 | 13.70 | 145 |
| 4G2.5 | 50 | 0.25 | 2.00 | 10.6 | 8.21 | 222 |
| 4G4.0 | 56 | 0.30 | 2.60 | 13.2 | 5.09 | 346 |
| 4G6.0 | 84 | 0.30 | 3.20 | 15.6 | 3.39 | 497 |
| 5G1.0 | 32 | 0.20 | 1.30 | 8.8 | 20.00 | 136 |
| 5G1.5 | 30 | 0.25 | 1.60 | 9.6 | 13.70 | 175 |
| 5G2.5 | 50 | 0.25 | 2.00 | 11.6 | 8.21 | 268 |
| 7G0.75 | 24 | 0.20 | 1.13 | 9.2 | 26.70 | 148 |
| 7G1.5 | 30 | 0.25 | 1.60 | 10.4 | 13.70 | 220 |
| 12G1.5 | 30 | 0.25 | 1.60 | 14.6 | 13.70 | 413 |
| 19G1.5 | 30 | 0.25 | 1.60 | 17.0 | 13.70 | 591 |
