AGKABEL Multicore Teflon Heat Resistant Cable – 600V PTFE
Ultra-high-temperature multicore cable designed for power control cabinets and harsh chemical environments. Features Nickel-plated copper Class 5 conductors, PTFE insulation, and a double PTFE tape binder with PTFE sheath. Compliant with DIN VDE 0482 and IEC 60332-1. Operating temperature range: -65°C to +260°C. Suitable for submersion in polluted liquids and aggressive environments. RoHS Compliant. Available in 2 and 3 Core configurations from 0.75mm² to 3.0mm².
AGKABEL GRUPPE LIMITED presents the Multicore Teflon Heat Resistant Cable, engineered for the most extreme thermal and chemical environments. The combination of Nickel-plated copper Class 5 conductors, PTFE insulation, and a double PTFE tape binder with a PTFE sheath ensures outstanding resistance to heat, chemicals, and corrosion. This cable is ideal for power control cabinets subjected to high thermal effects, as well as brickworks, heaters, kitchen fitments, and the chemical industry. It is also suitable for submersion in polluted liquids and aggressive environments, such as Waste Water Treatment Plants.
Construction & Standards
-
Standard: DIN VDE 0482 part 265-2-1 / EN 50265-2-1 / IEC 60332-1
-
Voltage: 600 Volt
-
Conductor: Nickel plated copper conductors stranded to IEC 60228 Class 5 (Flexible)
-
Insulation: PTFE
-
Binder: Double PTFE Tape (2*8*0.06mm)
-
Sheath: PTFE
-
Operating Temperature: -65°C to +260°C
-
Sheath Marking: Manufacture name (trademark) and type, Production year/week or batch number, Metre-marked
-
Compliance: RoHS Compliant
Application
Power Control cabinets subjected to high thermal effects as well as brickworks, heaters, kitchen fitments as well as the chemical industry. Waste Water Treatment Plants. Suitable for submersion in polluted liquids & aggressive environments.
Technical Specifications Table
| No. of Cores/mm² | No. of strands | Wire/Dia. (mm) | Insulation Dia. (mm) | Sheath Dia. (mm) | Max. DC Resistance at 20°C (Ohm/km) | Approx. weight (kg/km) |
|---|---|---|---|---|---|---|
| TWO CORE | ||||||
| 2*0.75 | 19 | 0.203 | 1.40 | 3.76 | 34.50 | 26.71 |
| 2*1.0 | 19 | 0.254 | 1.65 | 4.32 | 23.00 | 36.56 |
| 2*1.5 | 19 | 0.287 | 1.83 | 4.67 | 14.70 | 42.98 |
| 2*2.0 | 19 | 0.361 | 2.26 | 5.53 | 8.79 | 61.34 |
| 2*3.0 | 37 | 0.320 | 2.75 | 6.68 | 5.41 | 75.15 |
| THREE CORE | ||||||
| 3*0.75 | 19 | 0.203 | 1.40 | 4.63 | 34.50 | 40.78 |
| 3*1.0 | 19 | 0.254 | 1.65 | 5.20 | 23.00 | 53.02 |
| 3*1.5 | 19 | 0.287 | 1.83 | 5.57 | 14.70 | 67.31 |
| 3*2.0 | 19 | 0.361 | 2.26 | 6.41 | 8.79 | 85.88 |
| 3*3.0 | 37 | 0.320 | 2.75 | 7.02 | 5.41 | 105.20 |
