AGKABEL Flexible Control Cables PVC/NBR – 300/500 Volt

AGKABEL GRUPPE LIMITED presents the Flexible Control Cables PVC/NBR, engineered for reliable performance in demanding industrial environments. Designed specifically for applications requiring numbered control cables, this multicore cable features a robust construction that ensures flexibility and durability. The PVC V-90 Black insulation is lettered and numbered for easy identification, while the NBR R90°C sheath provides excellent resistance to oil, abrasion, and mechanical stress.

Construction & Standards

• Standard: AS/NZS 3147, AS/NZS 3191, AS/NZS 3808, IEC 60332-1

• Voltage: 300/500 Volt

• Conductor: Plain annealed copper stranded to IEC 60228 Class 5 (Flexible)

• Insulation: PVC, V-90 Black (lettered & numbered) & Green/Yellow

• Sheath: NBR R90°C Grey or Black

• Max. Operating Temp:

  • Flexing: -5°C to +70°C

  • Static: -30°C to +80°C

• Sheath Marking: Manufacture name (trademark) and type, Production year/week or batch number, Metre-marked


  AGKABEL GRUPPE LIMITED presents the Flexible Control Cables PVC/NBR, engineered for reliable performance in demanding industrial environments. Designed specifically for applications requiring numbered control cables, this multicore cable features a robust construction that ensures flexibility and durability. The PVC V-90 Black insulation is lettered and numbered for easy identification, while the NBR R90°C sheath provides excellent resistance to oil, abrasion, and mechanical stress.

  Construction & Standards

  • Standard: AS/NZS 3147, AS/NZS 3191, AS/NZS 3808, IEC 60332-1

  • Voltage: 300/500 Volt

  • Conductor: Plain annealed copper stranded to IEC 60228 Class 5 (Flexible)

  • Insulation: PVC, V-90 Black (lettered & numbered) & Green/Yellow

  • Sheath: NBR R90°C Grey or Black

  • Max. Operating Temp:

    • Flexing: -5°C to +70°C

    • Static: -30°C to +80°C

  • Sheath Marking: Manufacture name (trademark) and type, Production year/week or batch number, Metre-marked

  Application
  Machine tools, construction and engineering equipment, conveyors and load banks or other applications requiring numbered control cables.

  Technical Specifications Table

  No. of Cores/mm²	No. of strands	Dia. (mm)	Insulation Thickness (mm)	Approx. Diameter (mm)	Max. DC Resistance at 20°C (Ohm/km)	Approx. weight (kg/km)
  3*0.5	16	0.20	0.5	5.1	39.00	42
  3*0.75	24	0.20	0.6	5.7	26.00	55
  3*1.0	32	0.20	0.6	6.0	19.50	65
  3*1.5	30	0.25	0.7	6.7	13.30	81
  4*0.5	16	0.20	0.5	5.7	39.00	50
  4*0.75	24	0.20	0.6	6.2	26.00	66
  4*1.0	32	0.20	0.6	6.5	19.50	77
  4*1.5	30	0.25	0.7	7.2	13.30	99
  5*0.5	16	0.20	0.5	6.2	39.00	63
  5*0.75	24	0.20	0.6	6.7	26.00	79
  5*1.0	32	0.20	0.6	7.1	19.50	94
  5*1.5	30	0.25	0.7	8.1	13.30	122
  7*0.5	16	0.20	0.5	6.7	39.00	81
  7*0.75	24	0.20	0.6	7.3	26.00	98
  7*1.0	32	0.20	0.6	8.0	19.50	124
  7*1.5	30	0.25	0.7	9.0	13.30	159
  12*0.5	16	0.20	0.5	8.9	39.00	136
  12*0.75	24	0.20	0.6	10.0	26.00	172
  12*1.0	32	0.20	0.6	10.5	19.50	202
  12*1.5	30	0.25	0.7	12.0	13.30	277
  12*2.5	50	0.25	0.8	14.8	7.98	424
