AGKABEL Submersible Halogen Free Flexible Cables – EPDM/Polyurethane
Heavy-duty, halogen-free flexible cable designed for power supply to machinery and motors in construction, shipyards, agriculture, and refrigeration. Features Plain Annealed Copper Class 5 conductors, EPDM compound Type EI6 insulation, and a Halogen-Free Polyurethane (TMPU) sheath. Compliant with EN50525, HD22.10, VDE0282-10, AS3116, and AS/NZS 3808. Temperature range: -40°C to +90°C (Static). Available in H05BQ-F (300/500V) and H07BQ-F (450/750V) configurations.
AGKABEL GRUPPE LIMITED presents the Submersible Halogen Free Flexible Cables EPDM/Polyurethane, engineered for reliable power transmission in demanding environments. Designed as a power cord for machinery and motors used on construction sites, shipyards, and in agriculture, this cable performs excellently in dry, humid, or wet areas subject to medium mechanical damage. It is also suitable for use in refrigeration areas. The halogen-free construction ensures safety in fire situations, while the EPDM insulation and polyurethane sheath provide outstanding durability and flexibility.
Construction & Standards
-
Standard: EN50525, HD22.10, VDE0282-10, AS3116, AS/NZS 3808
-
Voltage: 300/500V (H05BQ-F) and 450/750V (H07BQ-F)
-
Conductor: Plain annealed copper stranded to IEC 60228 Class 5 (Flexible)
-
Insulation: EPDM compound type EI6
-
Sheath: Halogen free polyurethane compound type TMPU
-
Temperature Range: -40 to +90°C (Static)
-
Sheath Marking: Manufacture name (trademark) and type, Production year/week or batch number, Metre-marked
Application
Power cord for machineries, motors used on construction sites and in shipyards as well as in agriculture; in dry, humid or wet areas subjected to medium mechanical damage. Use in the area of refrigeration also possible.
Technical Specifications Table
| No. of Cores (mm²) | No. of strands | Dia. (mm) | Overall Diameter Min. (mm) | Overall Diameter Max. (mm) | Max. DC Resistance at 20°C (Ohm/km) | Approx. Weight (kg/km) |
|---|---|---|---|---|---|---|
| H05BQ-F 300/500V | ||||||
| 2*0.75 | 24/0.20 | 1.1 | 5.7 | 7.4 | 26.70 | 53 |
| 2*1.0 | 32/0.20 | 1.3 | 6.1 | 8 | 20.00 | 60 |
| 3G0.75 | 24/0.20 | 1.1 | 6.2 | 8.1 | 26.70 | 66 |
| 3G1.0 | 32/0.20 | 1.3 | 6.5 | 8.5 | 20.00 | 72 |
| 4G0.75 | 24/0.20 | 1.1 | 6.8 | 8.8 | 26.70 | 82 |
| 4G1.0 | 32/0.20 | 1.3 | 7.1 | 9.3 | 20.00 | 91 |
| 5G0.75 | 24/0.20 | 1.1 | 7.6 | 9.9 | 26.70 | 100 |
| 5G1.0 | 32/0.20 | 1.3 | 8 | 10.3 | 20.00 | 112 |
| H07BQ-F 450/750V | ||||||
| 2*1.5 | 30/0.25 | 1.6 | 7.6 | 9.8 | 13.70 | 91 |
| 2*2.5 | 50/0.25 | 2.1 | 9.0 | 11.6 | 8.21 | 101 |
| 2*4.0 | 56/0.30 | 2.6 | 10.6 | 13.7 | 5.09 | 154 |
| 2*6.0 | 84/0.30 | 3.2 | 11.8 | 15.1 | 3.51 | 232 |
| 3G1.5 | 30/0.25 | 1.6 | 8.0 | 10.4 | 13.70 | 110 |
| 3G2.5 | 50/0.25 | 2.1 | 9.6 | 12.4 | 8.21 | 160 |
| 3G4.0 | 56/0.30 | 2.6 | 11.3 | 14.5 | 5.09 | 264 |
| 3G6.0 | 84/0.30 | 3.2 | 12.8 | 16.3 | 3.51 | 346 |
| 4G1.5 | 30/0.25 | 1.6 | 9.0 | 11.6 | 13.70 | 143 |
| 4G2.5 | 50/0.25 | 2.1 | 10.7 | 13.8 | 8.21 | 200 |
| 4G4.0 | 56/0.30 | 2.6 | 12.7 | 16.2 | 5.09 | 277 |
| 4G6.0 | 84/0.30 | 3.2 | 14.2 | 18.1 | 3.51 | 414 |
| 5G1.5 | 30/0.25 | 1.6 | 9.8 | 12.7 | 13.70 | 170 |
| 5G2.5 | 50/0.25 | 2.1 | 11.9 | 15.3 | 8.21 | 260 |
| 5G4.0 | 56/0.30 | 2.6 | 14.1 | 17.9 | 5.09 | 345 |
| 5G6.0 | 84/0.30 | 3.2 | 15.7 | 20.0 | 3.51 | 518 |
Factory Overview
Packaging & Shipping
❓ Frequently Asked Questions (FAQ)
1. What are the primary applications for this cable?
It is designed as a power cord for machinery and motors used on construction sites, shipyards, and in agriculture. It is suitable for dry, humid, or wet areas subject to medium mechanical damage and can also be used in refrigeration areas.
2. What is the temperature range of this cable?
The temperature range is -40°C to +90°C (Static) .
3. What materials are used for the conductor and insulation?
The conductor is Plain Annealed Copper stranded to IEC 60228 Class 5 (Flexible). The insulation is EPDM compound type EI6 and the sheath is Halogen-Free Polyurethane (TMPU) .
4. What is the voltage rating of this cable?
-
H05BQ-F: 300/500V
-
H07BQ-F: 450/750V
5. What standards does this cable comply with?
It complies with EN50525, HD22.10, VDE0282-10, AS3116, and AS/NZS 3808.
6. What sizes and core configurations are available?
Available in configurations from 2 to 5 cores, with conductor sizes ranging from 0.75mm² to 6.0mm².
7. What is the benefit of the halogen-free construction?
Halogen-free cables emit very little smoke and no toxic halogens in a fire, making them safer for enclosed spaces and sensitive environments.
