Angecable - Single Core Silicone Halogen Free Flexible Cable SIAF 180°C

AGKABEL GRUPPE LIMITED presents the Single Core Silicone Halogen Free Flexible Cable (SIAF 180°C), engineered for superior performance in extreme temperatures and safety-critical environments. The combination of Tinned Copper Class 5 conductors and Silicone Rubber insulation makes this cable highly flexible and resistant to heat, making it ideal for a wide range of industrial, commercial, and transportation applications. Being halogen-free, it ensures minimal toxic smoke emission in the event of a fire.

Construction & Standards

Standard: AS/NZS 5000
Voltage: 600/1000 V
Conductor: Tinned copper stranded to IEC 60228 Class 5 (Flexible)
Insulation: Silicone Rubber
Temperature Range: -60°C to +180°C
Sheath Marking: Manufacture name (trademark) and type, Production year/week or batch number, Metre-marked

Application
Switchboards, Appliance wiring, stoves, ovens, public transport – railways etc, automotive and marine wiring.

Technical Specifications Table

Conductor (mm²)	No. of strands	Dia. (mm)	Insulation Thickness (mm)	Overall Diameter (mm)	Max. DC Resistance at 20°C (ohm/km)	Approximate Mass (kg/km)
0.75	24/0.20	1.13	0.6	2.4	26.700	13.3
1	32/0.20	1.30	0.6	2.5	20.000	15.9
1.5	30/0.25	1.60	0.6	2.8	13.700	21.9
2.5	50/0.25	2.00	0.7	3.4	8.210	34.7
4	56/0.30	2.60	0.8	4.2	5.090	54.4
6	84/0.30	3.20	0.8	5.2	3.390	82.3
10	80/0.40	4.20	1.0	6.4	1.950	131.9
16	126/0.40	5.20	1.2	8.0	1.240	209.1
25	196/0.40	6.50	1.4	10.0	0.795	326.7
