AGKABEL Loop Cable – Traffic Signal Detection (AS/NZS 2276.3)
Specialized single-core cable designed for traffic signal installations and vehicle detection loops. Features Tinned Annealed Copper conductors and Polypropylene insulation. Compliant with AS/NZS 2276.3:1992. Operating frequency range: 20 kHz to 200 kHz. Max operating temperature: 75°C. Designed for installation in slots cut into road surfaces. Available in 1.5mm² (7/0.5 strands).
AGKABEL GRUPPE LIMITED presents the Loop Cable, specifically engineered for traffic signal installations and inductive loop detection systems. Operating effectively in the frequency range of 20 kHz to 200 kHz, this cable is designed for durability and precise signal transmission. It is suitable for installation in slots cut into the road surface, with the slots subsequently filled with a suitable sealant to protect the cable and ensure long-term performance in harsh outdoor environments.
Construction & Standards
-
Standard: AS/NZS 2276.3: 1992
-
Conductor: Tinned Annealed Copper
-
Insulation: Polypropylene
-
Max. Operating Temperature: 75°C
-
Sheath Marking: Manufacture name (trademark) and type, Production year/week or batch number, Metre-marked
Application
For traffic signal installations operating in the frequency range 20 kHz to 200 kHz, and suitable for installation in slot cut into surface, the slots being subsequently filled with a suitable sealant.
Technical Specifications Table
| Conductor (mm²) | No. of strands | Overall Diameter Min. (mm) | Overall Diameter Max. (mm) | Max. DC Resistance at 20°C (ohm/km) | Approximate Mass (kg/km) |
|---|---|---|---|---|---|
| 1.5 | 7/0.5 | 3.5 | 3.7 | 13.900 | 20 |
Factory Overview
Packaging & Shipping
❓ Frequently Asked Questions (FAQ)
1. What is the primary application for this cable?
It is designed for traffic signal installations and inductive loop detection systems, operating in the frequency range of 20 kHz to 200 kHz.
2. How is this cable installed?
It is suitable for installation in slots cut into the road surface, with the slots subsequently filled with a suitable sealant.
3. What materials are used for the conductor and insulation?
The conductor is Tinned Annealed Copper and the insulation is Polypropylene.
4. What is the maximum operating temperature?
The maximum operating temperature is 75°C.
5. What standard does this cable comply with?
It complies with AS/NZS 2276.3: 1992.
6. What size is available?
The available size is 1.5mm² with 7/0.5 strands.
