AGKABEL Flexible Control Cables PVC/PVC – 300/500 Volt
High-flexibility multicore control cable designed for machine tools, construction equipment, conveyors, and load banks. Features Plain Annealed Copper Class 5 conductors, PVC V-90 Black numbered insulation, and a durable PVC 4V-90 sheath (Grey or Black). Compliant with AS/NZS 3147, AS/NZS 3191, AS/NZS 3808, and IEC 60332-1. Temperature range: -5°C to +70°C (Flexing) | -30°C to +80°C (Static). Available from 3 to 12 cores, 0.5mm² to 2.5mm².
AGKABEL GRUPPE LIMITED presents the Flexible Control Cables PVC/PVC, engineered for reliable performance in demanding industrial environments. Designed specifically for applications requiring numbered control cables, this multicore cable features a robust construction that ensures flexibility and durability. The PVC V-90 Black insulation is lettered and numbered for easy identification, while the PVC 4V-90 sheath provides excellent mechanical protection.
Construction & Standards
-
Standard: AS/NZS 3147, AS/NZS 3191, AS/NZS 3808, IEC 60332-1
-
Voltage: 300/500 Volt
-
Conductor: Plain annealed copper stranded to IEC 60228 Class 5 (Flexible)
-
Insulation: PVC, V-90 Black (lettered & numbered) & Green/Yellow
-
Sheath: PVC, 4V-90 Grey or Black
-
Max. Operating Temp:
-
Flexing: -5°C to +70°C
-
Static: -30°C to +80°C
-
-
Sheath Marking: Manufacture name (trademark) and type, Production year/week or batch number, Metre-marked
Application
Machine tools, construction and engineering equipment, conveyors and load banks or other applications requiring numbered control cables.
Technical Specifications Table
| No. of Cores/mm² | No. of strands | Dia. (mm) | Insulation Thickness (mm) | Approx. Diameter (mm) | Max. DC Resistance at 20°C (Ohm/km) | Approx. weight (kg/km) |
|---|---|---|---|---|---|---|
| 3*0.5 | 16 | 0.20 | 0.5 | 5.1 | 39.00 | 42 |
| 3*0.75 | 24 | 0.20 | 0.6 | 5.7 | 26.00 | 55 |
| 3*1.0 | 32 | 0.20 | 0.6 | 6.0 | 19.50 | 65 |
| 3*1.5 | 30 | 0.25 | 0.7 | 6.7 | 13.30 | 81 |
| 4*0.75 | 24 | 0.20 | 0.6 | 6.2 | 26.00 | 66 |
| 4*1.0 | 32 | 0.20 | 0.6 | 6.5 | 19.50 | 77 |
| 4*1.5 | 30 | 0.25 | 0.7 | 7.2 | 13.30 | 99 |
| 5*0.5 | 16 | 0.20 | 0.5 | 6.2 | 39.00 | 63 |
| 5*0.75 | 24 | 0.20 | 0.6 | 6.7 | 26.00 | 79 |
| 5*1.0 | 32 | 0.20 | 0.6 | 7.1 | 19.50 | 94 |
| 5*1.5 | 30 | 0.25 | 0.7 | 8.1 | 13.30 | 122 |
| 7*0.5 | 16 | 0.20 | 0.5 | 6.7 | 39.00 | 81 |
| 7*0.75 | 24 | 0.20 | 0.6 | 7.3 | 26.00 | 98 |
| 7*1.0 | 32 | 0.20 | 0.6 | 8.0 | 19.50 | 124 |
| 7*1.5 | 30 | 0.25 | 0.7 | 9.0 | 13.30 | 159 |
| 12*0.5 | 16 | 0.20 | 0.5 | 8.9 | 39.00 | 136 |
| 12*0.75 | 24 | 0.20 | 0.6 | 10.0 | 26.00 | 172 |
| 12*1.0 | 32 | 0.20 | 0.6 | 10.5 | 19.50 | 202 |
| 12*1.5 | 30 | 0.25 | 0.7 | 12.0 | 13.30 | 277 |
| 12*2.5 | 50 | 0.25 | 0.8 | 14.8 | 7.98 | 424 |
Factory Overview
Packaging & Shipping
❓ Frequently Asked Questions (FAQ)
1. What are the primary applications for this cable?
It is ideal for machine tools, construction and engineering equipment, conveyors, load banks, and other applications requiring numbered control cables.
2. What is the temperature range of this cable?
-
Flexing: -5°C to +70°C
-
Static: -30°C to +80°C
3. What materials are used for the conductor and insulation?
The conductor is Plain Annealed Copper stranded to IEC 60228 Class 5 (Flexible). The insulation is PVC, V-90 Black (lettered & numbered) & Green/Yellow.
4. What is the sheath material?
The sheath is PVC, 4V-90, available in Grey or Black.
5. What is the voltage rating of this cable?
The voltage rating is 300/500 Volt.
6. What standards does this cable comply with?
It complies with AS/NZS 3147, AS/NZS 3191, AS/NZS 3808, and IEC 60332-1.
7. What sizes and core configurations are available?
Available from 3 to 12 cores, with conductor sizes ranging from 0.5mm² to 2.5mm².
