AGKABEL Security / Audio Cables (Figure 8) – 30V
Specialized Figure 8 cable designed for the transmission of sound, broadcast, and audio signals. Features Plain Annealed Copper Class 5 conductors and a V-90HT PVC sheath. Compliant with AS/NZS 5000, AS/NZS 1125, IEC 60228, IEC 60332-1, and AS/NZS 3808. Max operating temperature: 105°C. Available from 0.5mm² to 2.6mm².
AGKABEL Single Core Silicone Halogen Free Flexible Cable – SIAF 180°C
High-temperature, halogen-free flexible cable designed for demanding applications. Features Tinned Copper Class 5 conductors and silicone rubber insulation. Compliant with AS/NZS 5000. Ideal for switchboards, appliance wiring, stoves, ovens, public transport (railways), automotive, and marine wiring. Temperature range: -60°C to +180°C. Available from 0.75 mm² to 25 mm².
AGKABEL Steel Braided Flexible Cables – 0.6/1kV EPR/LSZH
Heavy-duty, halogen-free flexible cable designed for power, automotive, and welding applications requiring extra mechanical protection. Features Plain Annealed Copper Class 5 conductors, EPR R-E-110 insulation, and a Low Smoke Zero Halogen (LSZH) HF-110-R sheath (Black, Blue, Red, or Orange). Compliant with IEC 60228, AS/NZS 1125, IEC 60332-1, and AS/NZS 5000.1. Temperature range: -40°C to +110°C (Static) | -25°C to +90°C (Flexing). Available from 16mm² to 630mm².
AGKABEL Steel Braided Flexible Cables – 300/500V
Heavy-duty, steel-braided flexible cable designed for extra mechanical protection in demanding industrial and marine environments. Features Plain Annealed Copper Class 5 conductors, NBR insulation (Black, lettered & numbered), Galvanized Steel Wire Braid (≥82% coverage), and a specialized highly flexible PVC inner sheath and NBR outer sheath. Compliant with 600/1000V standard. Temperature range: -20°C to +90°C (Flexing) | -30°C to +90°C (Static). RoHS Compliant. Available from 3 to 7 cores, 1.5mm² to 2.5mm².
AGKABEL Submersible Halogen Free Flexible Cables – EPDM/Polyurethane
Heavy-duty, halogen-free flexible cable designed for power supply to machinery and motors in construction, shipyards, agriculture, and refrigeration. Features Plain Annealed Copper Class 5 conductors, EPDM compound Type EI6 insulation, and a Halogen-Free Polyurethane (TMPU) sheath. Compliant with EN50525, HD22.10, VDE0282-10, AS3116, and AS/NZS 3808. Temperature range: -40°C to +90°C (Static). Available in H05BQ-F (300/500V) and H07BQ-F (450/750V) configurations.
AGKABEL Submersible Rubber Flexibles – Type NSGAFöu (1.9/3.3kV)
High-voltage, heavy-duty flexible cable designed for fixed installation in traction applications and marine environments. Features Tinned Stranded Copper Class 5 conductors, extremely flexible EPR Type 3G13 insulation, and a durable CPE Rubber sheath. Compliant with AS/NZS 5000.1, AS/NZS 1125, IEC 60228, IEC 60332-1, and AS/NZS 3808. Temperature range: -40°C to +110°C (Static) | -20°C to +90°C (Flexing). Suitable for submersible pumps to 100 metres depth. Available from 1.5mm² to 500mm².
AGKABEL Submersible Screened & Unscreened Cables – 600/1000V EPR/CPE
Heavy-duty, flexible submersible cable designed for medium mechanical loads in dry, damp, and hazardous locations. Features Tinned Stranded Copper Class 5 conductors, EPR Type 3G13 insulation, and a CPE (M) Blue sheath. Screened versions feature an Aluminium/Mylar tape + Tinned Copper Braid (≥82% coverage). Compliant with AS/NZS 5000.1, AS/NZS 1125, IEC 60228, and IEC 60332-1. Suitable for submersible pumps up to 100 meters depth. Available from 1.5mm² to 10.0mm².
AGKABEL Unscreened Fire Alarm Cables – 12/80V
Specialized fire alarm cable designed for commercial and industrial installations. Features Plain Annealed Copper Class 2 conductors, V-90HT PVC insulation, and an easy-peel V-90HT PVC sheath. Compliant with AS/NZS 5000, AS/NZS 1125, IEC 60228, IEC 60332-1, and AS/NZS 3808. Max operating temperature: 105°C. Available in 0.75mm², 1.0mm², and 1.5mm² in both circular and Figure 8 configurations.
AGKABEL PVC Flat Cables KYFLY – for Festoon Systems
Flexible PVC flat cables designed for use as trailing cables in crane installations, floor conveyor systems, and shelf control units. Temperature range: -5°C to +70°C (Flexing). Nominal voltage: 300/500 V. Features a flat construction for neat stacking and continuous flexing. Available in a wide variety of specialized configurations, including bundle (Bd) variants, from 0.5mm² to 1.5mm².
AGKABEL PVC Flat Cables for Festoon Systems – A05VVH6-F, H05VVH6-F, H07VVH6-F (HAR)
Flexible PVC flat cables designed for use as trailing cables in crane installations, floor conveyor systems, and shelf control units. Compliant with DIN VDE 0283 part 2, DIN VDE 0281 part 404, and IEC 60227-6. Temperature range: -5°C to +70°C (Flexing) | -40°C to +70°C (Fixed). Nominal voltage: 300/500 V (up to 1mm²) or 450/750 V (from 1.5mm²). Minimum bending radius: approx. 10 x cable diameter. Available from 4 to 24 cores, 0.75mm² and 1.0mm².
AGKABEL Heat-Resistant Silicone Multi-Core Cables SiHF-P – Steel Wire Braid, Halogen-Free
Heavy-duty, flexible multi-core cables with a galvanized steel wire braid for superior mechanical protection. Designed for industrial areas with increased temperature requirements and mechanical stress. Ideal for mechanical engineering, lighting industries, glass, ceramic, and steel fabrication. Temperature range: -50°C to +180°C. Rated voltage: 300/500 V. Test voltage: 2000 V. Available from 2 to 24 cores, 0.75mm² to 16mm².
AGKABEL Heat-Resistant Silicone Multi-Core Cables SiHF-P – Steel Wire Braid, Halogen-Free
Heavy-duty, flexible multi-core cables with a galvanized steel wire braid for superior mechanical protection. Designed for industrial areas with increased temperature requirements and mechanical stress. Ideal for mechanical engineering, lighting industries, glass, ceramic, and steel fabrication. Temperature range: -50°C to +180°C. Rated voltage: 300/500 V. Test voltage: 2000 V. Available from 2 to 24 cores, 0.75mm² to 16mm².
AGKABEL Heat-Resistant Silicone Multi-Core Cables SiHF-Cu-Si – EMC-Suitable, Cu-Screened, Halogen-Free
Flexible, copper-screened multi-core cables designed for industrial areas with increased temperature requirements and electromagnetic compatibility (EMC) needs. Ideal for mechanical engineering, lighting industries, glass, ceramic, and steel fabrication. Temperature range: -50°C to +180°C. Rated voltage: 300/500 V. Test voltage: 2000 V. Available from 2 to 18 cores, 0.5mm² to 16mm².
AGKABEL Heat-Resistant Silicone Multi-Core Cables SiF-Cu-Si – EMC-Suitable, Cu-Screened, Halogen-Free
Flexible, copper-screened multi-core cables designed for industrial areas with increased temperature requirements and electromagnetic compatibility (EMC) needs. Ideal for mechanical engineering, lighting industries, glass, ceramic, and steel fabrication. Temperature range: -50°C to +180°C. Rated voltage: 300/500 V. Test voltage: 2000 V. Available from 2 to 18 cores, 0.5mm² to 2.5mm².
AGKABEL Heat-Resistant Silicone Multi-Core Cables SiHF – Halogen-Free
AGKABEL Heat-Resistant Silicone Twin Cables SiFZw – Halogen-Free
Silicone twin cables designed for the internal wiring of lighting and appliances at high ambient temperatures. Features a halogen-free silicone construction for safety and flexibility. Temperature range: -50°C to +180°C. Rated voltage: 380 V. Test voltage: 2000 V. Available in 2-core configurations from 0.5mm² to 1.5mm².
AGKABEL Heat-Resistant Silicone Cables (SiD, SiF, A05SJ-U, H05SJ-K, SiFZü)
Halogen-free, silicone single-core cables designed for extreme high-temperature environments. Ideal for metallurgical industries, steel works, hot rolling mills, and automotive ignition systems. Resistant to vegetable/animal fats, oils, diluted acids, oxygen, and ozone. Compliant with DIN VDE and HAR V. Temperature range: -50°C to +180°C. Rated voltage: 300/500 V. Available from 0.25mm² to 240mm².
AGKABEL Rubber-Insulated Cables NSGAFöu – 1.8/3 kV & 3.6/6 kV
Special single-core rubber-insulated cables designed for short-circuit and earth-fault safety. Particularly suitable for inherently earth-fault-proof routing in rail vehicles and buses. Compliant with DIN VDE 0250 part 602. Temperature range: -25°C to +80°C (Flexing) | -40°C to +80°C (Fixed). Nominal voltage options: 1.8/3 kV and 3.6/6 kV. Suitable for laying in dry zones. Available from 1.5mm² to 300mm².
AGKABEL Rubber-Insulated Cables H01N2-D / H01N2-E – Ultra-Flexible Welding Cables
Ultra-flexible single-core rubber-sheathed cables designed for welding applications, including connection between welding generators and hand-electrodes. Ideal for the automotive industry, shipbuilding, transport/conveyor systems, tool making, and welding robots. Retains high flexibility under ozone, oxygen, light, aggressive gases, oil, and petrol. Resistant to cold, heat, and flames. Compliant with DIN VDE 0282 part 6 or HD 22.6 S2. Temperature range: -25°C to +80°C (Flexing) | -40°C to +80°C (Fixed). Nominal voltage: 100 V. Available from 10mm² to 185mm².
AGKABEL Rubber-Insulated Cables NSSHöu-O – Heavy-Duty for Mining
Extremely robust rubber-insulated connecting cables designed for very high mechanical stress in underground and surface mining, stone pits, building sites, and industrial environments. Features an EPR-based insulation that improves ozone resistance. Compliant with DIN VDE 0250 part 812 and IEC 60332-1. Temperature range: -25°C to +80°C (Flexing) | -40°C to +80°C (Fixed). Nominal voltage: 0.6/1 kV. Available from 1 to 5 cores, 1.5mm² to 300mm².
AGKABEL Rubber-Insulated Cables H07RN-F – Heavy-Duty, Flexible, VDE Approved
AGKABEL Rubber-Insulated Cables A07RN-F – Heavy-Duty, Flexible, VDE Approved
AGKABEL Lift Control Cables YSLTÖ – for Gravity-Fed Collector Basket Operation
Flexible, number-coded feeder cables designed for load-lifting equipment (e.g., spreaders) experiencing high mechanical stress in Gravity-Fed Collector Basket operations. Features a built-in suspension strand for vertical support and is available with or without integrated fibre-optics. Rated for unrestricted outdoor and indoor use, resistant to ozone, UV radiation, and moisture. Temperature range: -20°C to +60°C (Fully flexible/Fixed). Rated voltage: 300/500 V. Available from 20 to 48 cores, 1.0mm² to 3.5mm².
AGKABEL Lift Control Cables STN – Neoprene with Suspension Strand
Robust, weather-resistant control and power cables designed for machines, equipment, and appliances constantly exposed to harsh weather (building machinery, conveyor/hoist systems, dry docks). Features a central strain-bearing support strand, ozone-resistant core insulation, and a chloroprene (neoprene) outer jacket that is hardly flammable and abrasion-resistant. Compliant with DIN VDE 0250 part 807 and DIN VDE 0282. Temperature range: -30°C to +70°C (Flexing) | -40°C to +70°C (Fixed). Nominal voltage: 450/750 V. Available from 3 to 61 cores, 1.0mm² to 16mm².
