AGKABEL Parallel Twin Flexible Cables (Battery Cables) – 0.6/1kV
AGKABEL PUR Spiral Cables EPR/PUR – H05BQ-F / H07BQ-F
High-performance spiral cable designed for the most arduous applications, including robots, electric doors, heavy-duty machines, lifting ramps, and drilling machines. Features Plain Annealed Copper Class 5 conductors, EPR insulation, and a Halogen-Free Polyurethane (TMPU) sheath. Compliant with AS/NZS 3120 and AS/NZS 3112. Temperature range: -50°C to +90°C. Proven to withstand over 1 million operations without failure (tested at the Materials Testing Institute in Hannover). Available in 2 to 7 cores, 0.75mm² to 6.0mm².
AGKABEL PUR Spiral Cables V-90/PUR
High-quality spiral cable designed for use as a coil/feeder cable, ideally suited for kitchen and housekeeping utensils, lighting, and general appliance connections. Features Plain Annealed Copper Class 5 conductors, PVC V90°C insulation, and a Halogen-Free Polyurethane (TMPU) sheath. Compliant with AS/NZS 3120 and AS/NZS 3112. Temperature range: -5°C to +80°C. Offers high reset power, excellent appearance, and a long service life. Available in 2 to 25 cores, 0.75mm² to 3.0mm².
AGKABEL Rubber SDI Flexible Cables – NBR/NBR R-90°C (0.6/1kV)
Heavy-duty, rubber flexible cable designed for power, automotive, and welding applications. Features Plain Annealed Copper Class 5 conductors, extremely flexible NBR insulation, and a durable NBR sheath (Black, Blue, Red, or Orange). Compliant with IEC 60228, AS/NZS 1125, IEC 60332-1, and AS/NZS 5000.1. Temperature range: -30°C to +90°C (Static) | -20°C to +90°C (Flexing). Available from 6mm² to 400mm².
AGKABEL Screened EMC Flexible Cables – Ordinary Duty 300/500V
High-flexibility, screened multicore cable designed for EMC-critical applications. Features Plain Annealed Copper Class 5 conductors, PVC V90°C White numbered insulation, Tinned Copper Braid (85% minimum coverage), and a durable NBR Elastomer sheath. Compliant with AS/NZS 3147, AS/NZS 3191, and IEC 60332-1. Temperature range: -20°C to +90°C (Flexing) | -30°C to +90°C (Static). Available from 2 to 25 cores, 0.5mm² to 2.5mm².
AGKABEL Screened PUR Energy / Drag Chain Cable – 300/500V 80°C
High-flexibility screened cable designed for continuous movement in energy/drag chains. Features Plain Annealed Copper Class 6 conductors, Special V75 STPE insulation, Tinned Copper Braid screen, and a Halogen-Free Polyurethane (TMPU) sheath. Compliant with AS/NZS 5000.1, AS/NZS 1125, and AS/NZS 3808. Temperature range: -50°C to +80°C (Fixed) | -40°C to +80°C (Flexing). Available from 4G0.75 to 25G0.75 and 4G1.5 to 18G1.5.
AGKABEL Screened PUR Energy / Drag Chain Cable – 300/500V 80°C
High-flexibility screened cable designed for continuous movement in energy/drag chains. Features Plain Annealed Copper Class 6 conductors, Special V75 STPE insulation, STPE plus fleece core wrapping, Tinned Copper Braid screen (85% min coverage), and a Halogen-Free Polyurethane (TMPU) sheath. Compliant with AS/NZS 5000.1, AS/NZS 1125, and AS/NZS 3808. Temperature range: -50°C to +80°C (Fixed) | -40°C to +80°C (Flexing). Available from 4G0.75 to 25G0.75, 4G1.5 to 18G1.5, and 4G2.5.
AGKABEL Screened PUR Energy / Drag Chain Cable – Paired 300/500V 80°C
AGKABEL Screened VSD Drive Flexible Cable – XLPE/NBR 90°C 0.6/1kV
AGKABEL GRUPPE LIMITED presents the Screened VSD Drive Flexible Cable, specifically designed for the connection of AC Variable Speed Drives. This advanced cable incorporates an Aluminium/Mylar tape plus a tinned copper braid screening. For sizes 6mm² and above, it features 3 split earth cores for optimum performance against low and high-frequency Radio Frequency Interference (RFI) and Electromagnetic Interference (EMI). This ensures that RFI/EMI does not react with other devices outside the plant, maintaining the integrity of your industrial environment.
AGKABEL Screened VSD Drive Flexible Submersible Cable – EPR/CPE R90°C 0.6/1kV
AGKABEL Screened VSD Drive Flexible Submersible Cable – EPR/CPE R90°C 0.6/1kV
High-performance screened cable designed for AC Variable Speed Drives (VSD) and submersible applications up to 100 meters depth. Features EPR R-EP-90°C insulation and a dual-layer screen (aluminum/mylar tape + tinned copper braid ≥80%). Compliant with AS 5000.1, AS 3147, and IEC 60332-1. Temperature range: -30°C to +90°C. Available from 2.5 mm² to 185 mm² in various core configurations (up to 4C+1C).
AGKABEL Screened VSD SDI Single Core Flexible Submersible Cable – 1.9/3.3kV R90°C
High-voltage, single-core flexible cable engineered for large AC Variable Speed Drives (VSD) and submersible applications. Features tinned stranded copper conductors, flexible EPR Type 3G13 insulation, and dual screening (TC braid + Aluminium/Mylar tape) for maximum EMV protection. Compliant with AS/NZS 5000.1, IEC 60228, and IEC 60332-1. Temperature range: -40°C to +90°C (Static). Available from 120mm² to 240mm².
AGKABEL SDI Cables / PVC Single Core Copper
Double-insulated, easy-peel single-core cable designed for general wiring, direct burial, and underground ducts. Features Plain Annealed Copper Class 2 conductors, PVC V-90 insulation (Black, Red), and a PVC 3V-90 White sheath. Compliant with AS/NZS 5000.2 (1–16mm²) and AS/NZS 5000.1 (25–630mm²). Max operating temperature: 75°C. Suitable for glanding. Available from 1mm² to 630mm².
AGKABEL PVC Flat Cables KYFLY – for Festoon Systems
Flexible PVC flat cables designed for use as trailing cables in crane installations, floor conveyor systems, and shelf control units. Temperature range: -5°C to +70°C (Flexing). Nominal voltage: 300/500 V. Features a flat construction for neat stacking and continuous flexing. Available in a wide variety of specialized configurations, including bundle (Bd) variants, from 0.5mm² to 1.5mm².
AGKABEL PVC Flat Cables for Festoon Systems – A05VVH6-F, H05VVH6-F, H07VVH6-F (HAR)
Flexible PVC flat cables designed for use as trailing cables in crane installations, floor conveyor systems, and shelf control units. Compliant with DIN VDE 0283 part 2, DIN VDE 0281 part 404, and IEC 60227-6. Temperature range: -5°C to +70°C (Flexing) | -40°C to +70°C (Fixed). Nominal voltage: 300/500 V (up to 1mm²) or 450/750 V (from 1.5mm²). Minimum bending radius: approx. 10 x cable diameter. Available from 4 to 24 cores, 0.75mm² and 1.0mm².
AGKABEL Heat-Resistant Silicone Multi-Core Cables SiHF-P – Steel Wire Braid, Halogen-Free
Heavy-duty, flexible multi-core cables with a galvanized steel wire braid for superior mechanical protection. Designed for industrial areas with increased temperature requirements and mechanical stress. Ideal for mechanical engineering, lighting industries, glass, ceramic, and steel fabrication. Temperature range: -50°C to +180°C. Rated voltage: 300/500 V. Test voltage: 2000 V. Available from 2 to 24 cores, 0.75mm² to 16mm².
AGKABEL Heat-Resistant Silicone Multi-Core Cables SiHF-P – Steel Wire Braid, Halogen-Free
Heavy-duty, flexible multi-core cables with a galvanized steel wire braid for superior mechanical protection. Designed for industrial areas with increased temperature requirements and mechanical stress. Ideal for mechanical engineering, lighting industries, glass, ceramic, and steel fabrication. Temperature range: -50°C to +180°C. Rated voltage: 300/500 V. Test voltage: 2000 V. Available from 2 to 24 cores, 0.75mm² to 16mm².
AGKABEL Heat-Resistant Silicone Multi-Core Cables SiHF-Cu-Si – EMC-Suitable, Cu-Screened, Halogen-Free
Flexible, copper-screened multi-core cables designed for industrial areas with increased temperature requirements and electromagnetic compatibility (EMC) needs. Ideal for mechanical engineering, lighting industries, glass, ceramic, and steel fabrication. Temperature range: -50°C to +180°C. Rated voltage: 300/500 V. Test voltage: 2000 V. Available from 2 to 18 cores, 0.5mm² to 16mm².
AGKABEL Heat-Resistant Silicone Multi-Core Cables SiF-Cu-Si – EMC-Suitable, Cu-Screened, Halogen-Free
Flexible, copper-screened multi-core cables designed for industrial areas with increased temperature requirements and electromagnetic compatibility (EMC) needs. Ideal for mechanical engineering, lighting industries, glass, ceramic, and steel fabrication. Temperature range: -50°C to +180°C. Rated voltage: 300/500 V. Test voltage: 2000 V. Available from 2 to 18 cores, 0.5mm² to 2.5mm².
AGKABEL Heat-Resistant Silicone Multi-Core Cables SiHF – Halogen-Free
AGKABEL Heat-Resistant Silicone Twin Cables SiFZw – Halogen-Free
Silicone twin cables designed for the internal wiring of lighting and appliances at high ambient temperatures. Features a halogen-free silicone construction for safety and flexibility. Temperature range: -50°C to +180°C. Rated voltage: 380 V. Test voltage: 2000 V. Available in 2-core configurations from 0.5mm² to 1.5mm².
AGKABEL Heat-Resistant Silicone Cables (SiD, SiF, A05SJ-U, H05SJ-K, SiFZü)
Halogen-free, silicone single-core cables designed for extreme high-temperature environments. Ideal for metallurgical industries, steel works, hot rolling mills, and automotive ignition systems. Resistant to vegetable/animal fats, oils, diluted acids, oxygen, and ozone. Compliant with DIN VDE and HAR V. Temperature range: -50°C to +180°C. Rated voltage: 300/500 V. Available from 0.25mm² to 240mm².
AGKABEL Rubber-Insulated Cables NSGAFöu – 1.8/3 kV & 3.6/6 kV
Special single-core rubber-insulated cables designed for short-circuit and earth-fault safety. Particularly suitable for inherently earth-fault-proof routing in rail vehicles and buses. Compliant with DIN VDE 0250 part 602. Temperature range: -25°C to +80°C (Flexing) | -40°C to +80°C (Fixed). Nominal voltage options: 1.8/3 kV and 3.6/6 kV. Suitable for laying in dry zones. Available from 1.5mm² to 300mm².
AGKABEL Rubber-Insulated Cables H01N2-D / H01N2-E – Ultra-Flexible Welding Cables
Ultra-flexible single-core rubber-sheathed cables designed for welding applications, including connection between welding generators and hand-electrodes. Ideal for the automotive industry, shipbuilding, transport/conveyor systems, tool making, and welding robots. Retains high flexibility under ozone, oxygen, light, aggressive gases, oil, and petrol. Resistant to cold, heat, and flames. Compliant with DIN VDE 0282 part 6 or HD 22.6 S2. Temperature range: -25°C to +80°C (Flexing) | -40°C to +80°C (Fixed). Nominal voltage: 100 V. Available from 10mm² to 185mm².
AGKABEL Rubber-Insulated Cables NSSHöu-O – Heavy-Duty for Mining
Extremely robust rubber-insulated connecting cables designed for very high mechanical stress in underground and surface mining, stone pits, building sites, and industrial environments. Features an EPR-based insulation that improves ozone resistance. Compliant with DIN VDE 0250 part 812 and IEC 60332-1. Temperature range: -25°C to +80°C (Flexing) | -40°C to +80°C (Fixed). Nominal voltage: 0.6/1 kV. Available from 1 to 5 cores, 1.5mm² to 300mm².
AGKABEL Rubber-Insulated Cables H07RN-F – Heavy-Duty, Flexible, VDE Approved
AGKABEL Rubber-Insulated Cables A07RN-F – Heavy-Duty, Flexible, VDE Approved
AGKABEL Lift Control Cables YSLTÖ – for Gravity-Fed Collector Basket Operation
Flexible, number-coded feeder cables designed for load-lifting equipment (e.g., spreaders) experiencing high mechanical stress in Gravity-Fed Collector Basket operations. Features a built-in suspension strand for vertical support and is available with or without integrated fibre-optics. Rated for unrestricted outdoor and indoor use, resistant to ozone, UV radiation, and moisture. Temperature range: -20°C to +60°C (Fully flexible/Fixed). Rated voltage: 300/500 V. Available from 20 to 48 cores, 1.0mm² to 3.5mm².
AGKABEL Lift Control Cables STN – Neoprene with Suspension Strand
Robust, weather-resistant control and power cables designed for machines, equipment, and appliances constantly exposed to harsh weather (building machinery, conveyor/hoist systems, dry docks). Features a central strain-bearing support strand, ozone-resistant core insulation, and a chloroprene (neoprene) outer jacket that is hardly flammable and abrasion-resistant. Compliant with DIN VDE 0250 part 807 and DIN VDE 0282. Temperature range: -30°C to +70°C (Flexing) | -40°C to +70°C (Fixed). Nominal voltage: 450/750 V. Available from 3 to 61 cores, 1.0mm² to 16mm².
