AGKABEL Screened (Aluminium Foil) Fire Alarm Cables – 12/80V
Specialized fire alarm cable designed for commercial and industrial installations. Features Plain Annealed Copper Class 2 conductors, V-90HT PVC insulation, Aluminium Foil shielding with a Drain Wire (7/0.20TC), and an easy-peel V-90HT PVC sheath. Compliant with AS/NZS 5000, AS/NZS 1125, IEC 60228, IEC 60332-1, and AS/NZS 3808. Max operating temperature: 105°C. Available in 1.0mm² and 1.5mm².
AGKABEL GRUPPE LIMITED presents the Screened (Aluminium Foil) Fire Alarm Cables, specifically engineered for reliable signal transmission in fire detection and alarm systems. The cable features an Aluminium Foil screen with a drain wire to protect against electromagnetic interference, ensuring system integrity. The easy-peel sheath design allows for quick and efficient termination, making it ideal for general wiring in commercial and industrial installations where mechanical damage is not a concern.
Construction & Standards
-
Standard: AS/NZS 5000, AS/NZS 1125, IEC 60228, IEC 60332-1, AS/NZS 3808
-
Voltage: 12/80V
-
Conductor: Plain annealed copper stranded to IEC 60228 Class 2
-
Insulation: V-90HT PVC
-
Shielding: Aluminium Foil with Drain wire (7/0.20TC)
-
Sheath: V-90HT PVC (Easy-peel)
-
Max. Operating Temperature: 105°C
-
Sheath Marking: Manufacture name (trademark) and type, Production year/week or batch number, Metre-marked
Application
Easi-peel sheath for general wiring, unenclosed, in conduit, commercial and industrial installations where not subject to mechanical damage.
Technical Specifications Table
| Conductor (mm²) | No. of strands | Insulation (mm) | Sheath (mm) | Overall Diameter (mm) | Max. DC Resistance at 20°C (Ohm/km) | Shielding | Approx. weight (kg/km) |
|---|---|---|---|---|---|---|---|
| 1.0 | 7/0.4 | 0.6 | 0.9 | 6.2 | 21.2 | Al Foil + DW | 50 |
| 1.5 | 7/0.5 | 0.7 | 1.0 | 7.0 | 13.6 | Al Foil + DW | 70 |
Factory Overview
Packaging & Shipping
❓ Frequently Asked Questions (FAQ)
1. What are the primary applications for this cable?
It is ideal for general wiring, unenclosed, in conduit, commercial and industrial installations where not subject to mechanical damage, specifically for fire alarm systems.
2. What is the maximum operating temperature?
The maximum operating temperature is 105°C.
3. What materials are used for the conductor and insulation?
The conductor is Plain Annealed Copper stranded to IEC 60228 Class 2. The insulation is V-90HT PVC.
4. What type of shielding does this cable have?
It features an Aluminium Foil screen with a Drain Wire (7/0.20TC).
5. What is the voltage rating of this cable?
The voltage rating is 12/80V.
6. What standards does this cable comply with?
It complies with AS/NZS 5000, AS/NZS 1125, IEC 60228, IEC 60332-1, and AS/NZS 3808.
7. What sizes are available?
Available sizes are 1.0mm² and 1.5mm².
8. What is the benefit of the easy-peel sheath?
The easy-peel sheath design allows for quick and efficient termination, saving time during installation.
