AGKABEL GRUPPE LIMITED presents a comprehensive range of PVC Single Core Cables (H05V-U, H07V-U/R, H05V-K, H07V-K), engineered for reliable internal wiring and power distribution. These cables are designed for installation inside apparatus as well as for laying to lighting, in dry rooms, production facilities, switch and distributor boards, tubes, under and in plaster. The range includes solid (U) and stranded (R/K) conductors to suit various installation and flexibility requirements. Select variants are also available with UL/CSA approval for global applications.

Technical Data

Standard:
- H05V-K and H05V-U acc. to DIN VDE 0281-3
- H07V-K and H07V-U/R acc. to DIN VDE 0281 part 3, HD 21.3 S3 and IEC 60227-3
Temperature range:
- Flexing: -5°C to +70°C
- Fixed installation: -30°C to +80°C
Nominal voltage:
- H05… = 300/500 V
- H07… = 450/750 V
Test voltage:
- H05… = 2000 V
- H07… = 2500 V
Application: For installation inside apparatus as well as for laying to the lightings, in dry rooms, production facilities, switch and distributor boards, tubes, under and in plaster.

Technical Specifications Table (Sample Sizes)

H05V-U (Solid Conductor, 300/500 V)

Part N°	N° of cores x cross-sec mm²	Outer diameter ca. mm	Copper weight kg/km	Weight ca. kg/km
11802001	0,5	2,2	4,80	8,00
11802011	0,75	2,2	7,20	11,00
11802024	1	2,4	9,60	14,00
11802032	1,5	2,8	14,40	20,00
11802048	2,5	3,4	24,00	31,00

H07V-U (Solid Conductor, 450/750 V)

Part N°	N° of cores x cross-sec mm²	Outer diameter ca. mm	Copper weight kg/km	Weight ca. kg/km
11802032	1,5	2,8	14,40	20,00
11802048	2,5	3,4	24,00	31,00
11802058	4	3,9	38,00	46,00
11802072	6	4,4	58,00	67,00
11802080	10	5,6	96,00	109,00

H07V-R (Stranded Conductor, 450/750 V)

Part N°	N° of cores x cross-sec mm²	Outer diameter ca. mm	Copper weight kg/km	Weight ca. kg/km
11803003	16	7,2	154,00	185,00
11803005	25	8,9	240,00	290,00
11803008	35	10,0	336,00	390,00
11803011	50	12,1	480,00	525,00
11803014	70	13,5	672,00	735,00
11803017	95	15,8	912,00	1.010,00
11803020	120	17,4	1.152,00	1.260,00
11803023	150	19,4	1.440,00	1.540,00
11803025	185	22,0	1.776,00	1.940,00
11803028	240	25,0	2.304,00	2.550,00
11803029	300	27,0	2.880,00	3.180,00
11803040	400	o. r.	3.840,00	o. r.
11803041	500	o. r.	4.800,00	o. r.

(Further dimensions and sheath colours available on request. Standard core colours up to 2.5mm²: blue, brown, dark blue, yellow, grey, green, green-yellow, orange, pink, red, black, violet, white. * For these colours from 1.5mm² no HAR approval.)

Factory Overview

Packaging & Shipping

❓ Frequently Asked Questions (FAQ)

1. What are the primary applications for these cables?
They are designed for installation inside apparatus as well as for laying to the lighting, in dry rooms, production facilities, switch and distributor boards, tubes, under and in plaster.

2. What is the temperature range of these cables?

Flexing: -5°C to +70°C
Fixed installation: -30°C to +80°C

3. What is the difference between the H05 and H07 series?

H05 (H05V-U, H05V-K): Rated for 300/500 V with a test voltage of 2000 V.
H07 (H07V-U/R, H07V-K): Rated for 450/750 V with a test voltage of 2500 V.

4. What do the suffixes U, R, and K mean?

U: Solid conductor (single wire).
R: Stranded conductor (multi-wire, rigid).
K: Fine-stranded conductor (highly flexible).

5. Are these cables available with UL/CSA approval?
Yes, select variants are available with UL/CSA approval for global applications.

6. What standards do these cables comply with?
They comply with DIN VDE 0281-3, HD 21.3 S3, and IEC 60227-3.

7. What colours are available?
Standard core colours up to 2.5mm² include blue, brown, dark blue, yellow, grey, green, green-yellow, orange, pink, red, black, violet, and white. Further sheath colours are available on request.
